UR20 I/O Module UR20-16DI-P (Part Number 1315200000), 16-Channel Digital Input, DIN Rail

This listing corresponds to the UR20-16DI-P 1315200000 variant from the source UR20 I/O module title family. UR20-16DI-P is a 16-channel digital input remote I/O module for decentralized signal acquisition in industrial control systems. Based on published technical references, it uses an IP20 form factor with PUSH IN connection technology, fits TS 35 DIN rail cabinets, and is designed for typical cabinet operation in -20 to +60 C environments. In the package: 1 x UR20-16DI-P digital input I/O module.

• UR20 I/O module variant UR20-16DI-P, Part Number 1315200000; 16-channel digital input design for distributed PLC and cabinet control.
• Supports 24 VDC digital input applications and Type 1/Type 3 sensor behavior references under EN 61131-2 use cases.
• Slim 11.5 mm module width supports high channel density on TS 35 DIN rail installations.
• Industrial operating range -20 to +60 C (storage -40 to +85 C), with diagnostic-oriented module design and reverse-polarity protection.
• Package includes 1 x UR20-16DI-P module; this listing corresponds to the UR20-16DI-P 1315200000 variant from the source title family.
