Z-15GW22614-B Z-15GW Hinge-Lever Microswitch, SPDT, 125 VAC / 250 VAC / 480 VAC

Z-15GW22614-B is a hinge‑lever snap‑action microswitch from the Z-15GW family. The part is marked with the full variant code Z-15GW22614-B and is configured as an SPDT (single‑pole double‑throw) contact. Electrical markings on the housing indicate 125 VAC, 250 VAC and 480 VAC ratings, with horsepower indications of 1/8 HP at 125 VAC and 1/4 HP at 250 VAC. The hinge/lever actuator provides reliable mechanical actuation for limit and position sensing in appliances, control panels and industrial equipment. Fitment and terminal arrangement can vary between subvariants; please verify the printed model code and terminal layout against your application or the supplier datasheet before ordering.

• Exact model: Z-15GW22614-B — full variant code as shown on marketplace listings and product housing.
• Switch function: SPDT (single-pole double-throw) snap-action contact configuration for common/NO/NC switching.
• Electrical ratings: marked for 125 VAC, 250 VAC and 480 VAC; horsepower markings shown as 1/8 HP (125 VAC) and 1/4 HP (250 VAC). Verify datasheet for DC ratings and variant-specific limits.
• Actuator & application: hinge/lever (Z-15GW family) actuator for position and limit sensing in appliances, industrial controls and equipment panels.
• Package & fitment note: includes one Z-15GW22614-B microswitch. Confirm terminal style, actuator length and markings against your device before installation.
